Designed in Australia, our Edge Series luminaire are built to perform efficiently and effectively even in the Australian heat. The EDGE XM packs a powerful punch! Providing intense illumination with very little energy. Featuring a low-height heatsink, allowing it to fit into tight ceiling spaces.
• Precision reflector with clear lens – for better light distribution.
• Specially designed heat sink – for application in minimal ceiling spaces.
• Deep set lamp position – for visual comfort and glare control.
• Next-Generation LED chip technology – increasing efficiency & longevity.
| PRODUCT CODES: | FINISH: | COLOUR TEMPERATURE: |
| 118-ED3XM13W603 | White | 3000K |
| 118-ED3XM13W604 | White | 4000K |
| 118-ED3XM13B603 | Black | 3000K |
| 118-ED3XM13B604 | Black | 4000K |
| ACCESSORY CODES: | ACCESSORY: |
| 118-RFLX36 | 36° Reflector |
| 118-RFLX24 | 24° Reflector |
| 118-RFLX15 | 15° Reflector |
| PLEASE NOTE |
| Fittings come standard with 60° reflector. |
| 10W & 8W codes available upon request. |
Category:
Material:
Powder Coated Aluminium
IP Rating:
44
Light Source:
LED 11W | 8W | 6W
Lumen Output:
1065lm | 1070lm (3000K | 4000K)
Sizes:
Mounting Type:
Dimensions:
H 78mm x W Ø86mm
Heatsink Width Ø62mm
Cut Out Ø76mm
Line Drawing:
